Basic parameters

• Length*Width*Height (mm)

  12170*2550*3180

• Inner height (mm)

  2470

• Wheelbase (mm)

  6000

• Front/rear overhang (mm)

  2740/3430

• Tire

  295/80R22.5

• Min turning diameter (m)

  21.5

• Standard number of seats

  32-48

• Max passenger capacity

  90

• Fuel tank (L)

  250

• Max manufacturer's total mass (kg)

  18500

• Front/rear axle (kg)

  6400/12100

New energy power system

• Rated power (kW/rpm)

  199

• Rated torque (N·m/rpm)

  1100

• Displacement (L)

  7.2

• Emission

  Euro V

Seat

• Wheelchair area (city bus)

  ●

• Full air suspended driver seat

  ●

• Passenger seat

  CS001/YT15A

Interior

• Rear driver guardrail + decorative glass

  ●

• PU air duct

  ●

• Curtain

  ○

• PVC passenger seat

  ○

• Manual wheelchair ramp

  ●

• Roof hatch without ventilator

  ●

Exterior

• First passenger door: double-leaf in-swing door

  ●

• Second passenger door: double-leaf in-swing door

  ●

• Peony green fully-enclosed side window

  ●

• White single-layer glass sliding driver window

  ●

• Left/right split front windshield laminated glass

  ●

• Rear windshield light gray tempered bonded glass

  ●

A/C

• A/C

  Cooling-only

• Defroster

  Natural wind

Chassis

• Axle

  Front and rear disc brakes

• Air suspension

  ●

• ECAS electronic control lifting

  ●

• LHD

  ●

• EPB

  ●

Safety and driving assistance system

• ABS+EPB

  ●

• Tire pressure alarm (front tire only)

  ○

• Manual lever-type rear-view mirror

  ●

• Reversing radar

  ○

• Two 5KG fire extinguishers

  ●

• Two automatic fire extinguishing bombs in engine compartment

  ●

Audio-visual entertainment and lighting

• Daytime running light

  ●

• Front top 22-inch HD display

  ○

• Front destination board

  ○

• CCTV

  ●

• Headlamp, LED

  ●
